Features
· Good mechanical and environmental characteristics
· Soft, Flexible, Stable, easy to splice, rat bite protection, Apply to connections of long distance, outdoor, building cabling, combination cabling of fiber optic and electronic
· Flame retardant characteristics meet the requirements of relevant standards
· Improve existing function based on customers’ various requirements
Specifications
Cable Type | Cable diameter (mm) | Cable weight (Kg/KM) | Tensile N | Bend radius | Crush (N/100mm) | ||
short term | long term | dynamic | static | ||||
2.0GJFJKBV | Φ2.0±0.1 | 13.0 | 200 | 100 | 50 | 30 | 4500 |
3.0GJFJKBV | Φ3.0±0.1 | 22.0 | 600 | 300 | 60 | 30 | 3500 |
