Features
· Good mechanical and environmental characteristics
· Soft, Flexible, Stable, easy to splice, rat bite protection, Apply to connections of long distance, outdoor, building cabling, combination cabling of fiber optic and electronic
· Flame retardant characteristics meet the requirements of relevant standards
· Improve existing function based on customers’ various requirements
Specifications
Cable Type | Cable diameter (mm) | Cable weight (Kg/KM) | Tensile N | Bend radius | Crush (N/100mm) | ||
short term | long term | dynamic | static | ||||
3.0GJFJKV | Φ3.0±0.2 | 12.5 | 600 | 300 | 70 | 35 | 3000 |
4.8GJFJKV | Φ4.8±0.2 | 27.0 | 800 | 400 | 100 | 50 | 3000 |
