Features
• Good mechanical and environmental characteristics
• Soft, Flexible, Stable, easy to splice, rat bite protection, Apply to connections of long distance, outdoor, building cabling, combination cabling of fiber optic and electronic
• Flame retardant characteristics meet the requirements of relevant standards
• Improve existing function based on customers’ various requirements
Specifications
Cable Type | Cable diameter (mm) | Cable weight (Kg/KM) | Tensile N | Bend radius | Crush (N/100mm) | ||
short term | long term | dynamic | static | ||||
2.0GJFJKV | Φ2.0±0.1 | 6.5 | 150 | 80 | 50 | 30 | 4500 |
3.0GJFJKV | Φ3.0±0.1 | 11.0 | 450 | 200 | 60 | 30 | 3500 |
