Used For Field Operation Cable I

Specification Download

@Email to Sales

Features

· Good mechanical and environmental characteristics.

· The mechanical characteristics meet the requirements of relevant standards.

· High intensity and light weight.

· Easy to splice and convenient laying,and with big capacity data transmission.

· various requirements of market and clients.

Application
· Used as field cable.
· Used in outside cabling.
· Used in poor condition outside cabling.
· Used in temporary cabling,meets the requirements of repeat cabling.

Specifications

Fiber Cable Count	Dimension (mm)	Cable Weight (kg/km)	Tensile(N) Long Term Short Term		Crush(N/100mm) Long Term Short Term		Min.bend Radius(mm) Dynamic Static		Range of Long Temperature(°C)
Used For Field Operation Cable I
2	5.2	24	500	1000	500	1500	20D	10D
4	5.2	24	500	1000	500	1500	20D	10D	-20°C ~ +60°C
6	6.0	31	500	1000	500	1500	20D	10D

Note:1 The cable dimension and weight are in accordance with the tight-buffered fiber of 0.9mm outer diameter
Note:2 D is outer diamensionof the round cable
Note:3 The minimum bend radius(static)is 5D when G.657 fiber is used
