SC - Aircraft Nut Type Fast Connector

FIC Connector (Field Installable Connector) is specially for single fiber FTTH drop cable filed termination. It provides efficient assembly and high reliability connection to make it easy for the last meters optic cable termination for FTTH.

Specification Download

@Email to Sales

Features

•Good insertion loss ,high return loss

•Reliable optical performance

•Good connection stability

•Convenient for field installation

•nstalls fast,Operates easy

•Low cost

Application

•Patch panels

•Distribution frames

•Maintenance or emergency restoration of fiber networks

•FTTH Outlets

•Connection at the desk for LAN environments

Availability

• The connector can be chosed pc or APC.

Item	Specification
Insertion Loss	Typical ≤0.3dB, Maximum≤0.5dB
Return Loss	PC≥45dB,APC≥55dB
Durability	≤0.3dB typical change, 500 matings
Operating Temperature	-40°C ~ 85°C
Hpusing type	APC---Green;PC---Blue
